Phoenix Contact 1674710 Equivalent & Substitute Parts

Part Overview

The Phoenix Contact 1674710 is a female insert connector without contacts for the HEAVYCON® DD108 series heavy duty connector system. This component is designed for 108-position crimp termination applications with a voltage rating of 250V and current capacity of 10A. The part is currently classified as obsolete, making identification of suitable substitute components essential for ongoing system maintenance and new design implementations.

Substiute Parts

1674710

Phoenix ContactIn Stock: 7901674710 Datasheet

Current PartRFQ

1584130

Phoenix ContactIn Stock: 11151584130 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution for the Phoenix Contact 1674710 is determined by strict equivalence across the following critical parameters:

• Series compatibility: HEAVYCON® DD108
• Connector type: Insert without Contacts
• Gender: Female
• Position count: 108
• Size designation: B24
• Termination method: Crimp
• Electrical ratings: 250V voltage, 10A current capacity
• Contact type: CK 1.6-ED
• Housing material: Polyamide (PA), Nylon
• Flammability compliance: UL94 V-0

The substitute part 1584130 maintains full equivalence across all specified parameters while offering the advantage of active product status and improved availability.

Parameter Comparison

Engineering Selection Recommendations

The Phoenix Contact 1584130 is the direct substitute for the obsolete 1674710. Both components are manufactured by Phoenix Contact and maintain identical electrical, mechanical, and environmental specifications within the HEAVYCON® DD108 series. The 1584130 offers the advantage of active product status with confirmed inventory availability, making it the appropriate selection for applications requiring the 108-position female insert connector without contacts.

Both parts satisfy ROHS3 compliance and REACH unaffected status, ensuring regulatory alignment for current manufacturing and deployment requirements.

Frequently Asked Questions (FAQ)

Q: Can the 1584130 be used as a direct replacement for the 1674710?

A: Yes. The 1584130 is electrically and mechanically equivalent to the 1674710 across all specified parameters, including voltage rating, current capacity, position count, termination style, and operating temperature range.

Q: What is the primary difference between these two parts?

A: The 1674710 is classified as obsolete, while the 1584130 maintains active product status. Both components are functionally identical for the HEAVYCON® DD108 series application.

Q: Are there packaging differences between the two parts?

A: The 1674710 is supplied with unspecified packaging, while the 1584130 is supplied in bulk packaging. This distinction does not affect functional compatibility.

Q: Do both parts meet the same compliance standards?

A: Yes. Both the 1674710 and 1584130 are ROHS3 compliant, REACH unaffected, and rated UL94 V-0 for material flammability.

Q: What is the contact type specification for these connectors?

A: Both parts utilize the CK 1.6-ED contact type within the HEAVYCON® DD108 series framework.
