TE Connectivity 1623849-9 Trimmer Potentiometer Equivalent & Substitute Parts

Part Overview

The TE Connectivity 1623849-9 is a 5 kOhm, 0.5W through-hole trimmer potentiometer with PC pin termination and top adjustment capability. This component is classified as obsolete, necessitating identification of active equivalent parts for new designs and ongoing production requirements. The part features a cermet resistive element with 25-turn adjustment and rectangular form factor suitable for PC board mounting applications.

Substiute Parts

1623849-9

TE Connectivity Passive ProductIn Stock: 8271623849-9 Datasheet

Current PartRFQ

PV36W502C01B00

Bourns Inc.In Stock: 2441PV36W502C01B00 Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the TE Connectivity 1623849-9 is determined by strict equivalence across the following critical parameters:

• Electrical Specifications: Resistance value (5 kOhms), power rating (0.5W), tolerance (±10%), and temperature coefficient (±100ppm/°C) must match exactly
• Mechanical Configuration: Number of turns (25), adjustment type (top adjustment), mounting method (through hole), and termination style (PC pins) must be identical
• Material Composition: Resistive element material (cermet) must be equivalent
• Physical Dimensions: Form factor classification (rectangular) must align with the original design envelope

The Bourns Inc. PV36W502C01B00 satisfies all substitution criteria as a direct functional equivalent with active product status.

Parameter Comparison

Engineering Selection Recommendations

The Bourns Inc. PV36W502C01B00 is the direct functional substitute for the obsolete TE Connectivity 1623849-9. Selection of the Bourns component is supported by the following factors:

• Product Status: The Bourns part maintains active production status, ensuring long-term availability and supply chain continuity
• Electrical Equivalence: All critical electrical parameters including resistance, power rating, tolerance, and temperature coefficient are identical
• Mechanical Compatibility: Physical mounting configuration, termination style, and adjustment mechanism are fully compatible with the original design
• Regulatory Compliance: The Bourns substitute carries ROHS3 compliance certification and REACH affected status, meeting current environmental and regulatory requirements
• Inventory Availability: The substitute part is available in production quantities (2408 pcs in stock) compared to the limited obsolete inventory of the original part

Frequently Asked Questions (FAQ)

Q: Can the Bourns PV36W502C01B00 be used as a direct replacement for the TE Connectivity 1623849-9 in existing designs?

A: Yes. The Bourns part is electrically and mechanically equivalent across all specified parameters. The 5 kOhm resistance, 0.5W power rating, 25-turn adjustment, cermet material, and PC pin termination are identical. Physical dimensions differ slightly (9.60mm x 5.00mm versus 9.50mm x 4.70mm), but both maintain rectangular form factor classification suitable for through-hole PC board mounting.

Q: What is the significance of the product status difference between the two parts?

A: The TE Connectivity 1623849-9 is classified as obsolete, indicating discontinued production and limited remaining inventory. The Bourns PV36W502C01B00 maintains active product status with ongoing manufacturing, ensuring availability for new production runs and future procurement requirements.

Q: Are there compliance differences between the original and substitute part?

A: The Bourns substitute carries explicit ROHS3 compliance certification and REACH affected status designation. The original TE Connectivity part does not specify these compliance certifications. Both parts share the same ECCN (EAR99) and HTSUS classification.

Q: How do the physical dimensions affect component placement?

A: Both parts maintain rectangular form factor classification with similar overall dimensions. The Bourns part measures 9.60mm x 5.00mm compared to the original 9.50mm x 4.70mm. These minor dimensional variations are within typical PCB layout tolerances for through-hole components and do not affect functional compatibility or mounting hole alignment.

Q: What packaging format is available for the substitute part?

A: The Bourns PV36W502C01B00 is supplied in tube packaging, compared to the original part which does not specify packaging format. Tube packaging is standard for through-hole trimmer potentiometers and facilitates automated assembly processes.
