TE Connectivity AMP Connectors 1-487769-8 Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 1-487769-8 is an FFC (Flat Flexible) connector housing designed for female contacts with 20 positions at 0.100" (2.54mm) pitch. This component functions as a receptacle housing with detent lock mechanism, rated for 300V and 1.5A operation across an extended temperature range of -65°C to 105°C. The part is currently active in production with 1021 pieces available in inventory. Substitute parts are identified when equivalent electrical ratings, mechanical dimensions, and connector specifications align with the original component's functional requirements, enabling direct replacement in applications where the original part becomes unavailable or when alternative sourcing is required.

Substiute Parts

1-487769-8

TE Connectivity AMP ConnectorsIn Stock: 10401-487769-8 Datasheet

Current PartRFQ

0901560160

MolexIn Stock: 41670901560160 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the TE Connectivity 1-487769-8 is determined by alignment of the following critical parameters:

Position Count and Pitch: The substitute part must provide exactly 20 positions at 0.100" (2.54mm) pitch to ensure mechanical and electrical compatibility with mating connectors and flat flexible cable assemblies.

Connector Configuration: The substitute must function as a receptacle housing for female contacts with single-row configuration to maintain form factor and mounting compatibility.

Electrical Ratings: The substitute must meet or exceed the voltage rating of 300V and current rating of 1.5A to ensure safe operation within the original application's electrical parameters.

Operating Temperature Range: The substitute must support operation across the temperature envelope of -65°C to 105°C to maintain functionality across the full range of intended deployment environments.

Locking Mechanism: The substitute must incorporate a positive locking feature (detent lock or equivalent fastening mechanism) to ensure secure mating and prevent accidental disconnection.

Housing Material and Color: The substitute housing must be constructed from thermoplastic material in black color to maintain mechanical durability and visual identification consistency.

Moisture Sensitivity and Compliance: The substitute must maintain MSL 1 (Unlimited) classification and comply with applicable regulatory standards including RoHS and REACH requirements where applicable.

Parameter Comparison

Engineering Selection Recommendations

TE Connectivity 1-487769-8: This part is the primary specification component with active product status and established inventory availability of 1021 pieces. The part carries UL94 V-0 flammability certification and operates across the extended temperature range of -65°C to 105°C. Selection of this part is appropriate when the original design specification calls for FFC connector housing with detent lock mechanism and when supply chain continuity with the original manufacturer is prioritized.

Molex 0901560160: This part qualifies as a functional substitute based on matching position count (20), pitch (0.100"/2.54mm), single-row configuration, and black thermoplastic housing. The Molex part maintains MSL 1 classification and carries ROHS3 compliance certification. The operating temperature range of -55°C to 105°C covers the upper portion of the original specification range. The locking mechanism differs (locking ramp versus detent lock) but provides equivalent mechanical retention. The housing material is specified as Polyphenylene Oxide (PPO) rather than generic thermoplastic. This part is suitable for applications where the lower temperature limit of -55°C is acceptable and where ROHS3 compliance is required. Inventory availability is higher at 4090 pieces, supporting extended production runs or rapid fulfillment requirements.

Selection between these parts depends on specific application requirements regarding minimum operating temperature, regulatory compliance mandates, and locking mechanism preference. Both parts maintain active product status and unlimited moisture sensitivity classification.

Frequently Asked Questions (FAQ)

Q: What determines whether the Molex 0901560160 can replace the TE Connectivity 1-487769-8?

A: Substitution is valid when the application requirements align with the Molex part's specifications. The critical matching parameters are 20-position count, 0.100" (2.54mm) pitch, single-row configuration, 300V/1.5A electrical ratings, black thermoplastic housing, and MSL 1 classification. The Molex part's operating temperature minimum of -55°C (versus -65°C for the original) and locking ramp mechanism (versus detent lock) are the primary differences. If your application operates above -55°C and the locking ramp mechanism is functionally equivalent to your detent lock requirement, direct substitution is valid.

Q: Are the locking mechanisms interchangeable between these two parts?

A: The TE Connectivity part uses a detent lock mechanism while the Molex part uses a locking ramp. Both mechanisms provide positive retention and prevent accidental disconnection. The specific engagement method differs, but both are classified as positive locking features. Mechanical compatibility depends on the mating connector design. Verify that your mating connector is compatible with the locking ramp mechanism if substituting from detent lock.

Q: What is the significance of the housing material difference (Thermoplastic versus Polyphenylene Oxide)?

A: Polyphenylene Oxide (PPO) is a specific thermoplastic material with defined mechanical and thermal properties. The TE Connectivity part specifies generic thermoplastic material, while the Molex part specifies PPO. PPO provides superior chemical resistance and dimensional stability. Both materials support the stated operating temperature ranges and carry appropriate flammability ratings. The PPO specification in the Molex part represents a more precisely defined material composition.

Q: Does the Molex part's ROHS3 compliance affect compatibility?

A: ROHS3 compliance indicates the part meets Restriction of Hazardous Substances regulations. The TE Connectivity part lists RoHS status as "Not applicable," which does not indicate non-compliance but rather that the classification was not assigned. The Molex part's explicit ROHS3 compliance is advantageous for applications subject to regulatory requirements in regions where ROHS3 certification is mandatory. Both parts maintain MSL 1 classification and EAR99 export control status.

Q: Can I use the Molex 0901560160 in applications requiring operation below -55°C?

A: No. The Molex part's operating temperature range is specified as -55°C to 105°C. Applications requiring operation at -65°C must use the TE Connectivity 1-487769-8, which supports the full -65°C to 105°C range. Operating components outside their specified temperature range may result in material brittleness, mechanical failure, or electrical performance degradation.

Q: Are contacts included with either housing part?

A: No. Both the TE Connectivity 1-487769-8 and Molex 0901560160 are housing components supplied without contacts. Contacts must be procured separately and installed into the housing according to manufacturer specifications. Verify contact compatibility with the specific housing design before assembly.

Q: What is the significance of MSL 1 (Unlimited) classification for both parts?

A: MSL 1 (Unlimited) indicates that the component has unlimited shelf life and does not require moisture-controlled storage or handling. Both parts can be stored and handled under standard warehouse conditions without special environmental controls. This classification simplifies inventory management and reduces procurement complexity compared to higher MSL ratings.
