Part Overview

The Phoenix Contact 1413010 is a 2-position feed-through terminal block connector designed for wire gauges 12-28 AWG (0.2-4 mm²). This component operates at 24 A (IEC) / 20 A (UL) and 500 V (IEC) / 600 V (UL) with screw termination. The 1413010 is classified as Last Time Buy, indicating discontinuation. Identifying equivalent substitute parts is necessary to ensure continued availability and design continuity for applications currently using this connector.

Substiute Parts

1413010

Phoenix ContactIn Stock: 10671413010 Datasheet

Current PartRFQ

3248030

Phoenix ContactIn Stock: 31833248030 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the Phoenix Contact 1413010 is determined by the following critical parameters:

• Connector Type & Configuration: Feed-through terminal block with 2 positions, 1 level, and 5.2 mm terminal width
• Electrical Ratings: Minimum 24 A (IEC) and 500 V (IEC) capability; minimum 20 A (UL) and 300 V (UL) capability
• Wire Gauge Compatibility: Support for 12-28 AWG range (0.2-4 mm²)
• Termination Method: Screw termination
• Mechanical Compatibility: Identical physical footprint and mounting interface
• Material & Compliance: Polyamide insulation with appropriate flammability rating and RoHS compliance

The Phoenix Contact 3248030 qualifies as a substitute based on matching the core functional and mechanical parameters, though with specific parameter variations noted in the comparison table below.

Parameter Comparison

Engineering Selection Recommendations

The Phoenix Contact 3248030 is an active product substitute for the discontinued 1413010. Both components share identical mechanical interfaces, electrical current ratings, and IEC voltage specifications. The 3248030 offers improved product lifecycle status with active manufacturing support.

Key differences requiring evaluation:

• Wire Gauge Range: The 3248030 supports 12-24 AWG, which excludes the 28 AWG lower end of the original 1413010 range. Applications using 28 AWG conductors require confirmation of compatibility or alternative sourcing.
• UL Voltage Rating: The 3248030 is rated 300 V (UL) compared to 600 V (UL) for the 1413010. Applications requiring 600 V UL compliance must verify that 300 V rating is acceptable for the intended circuit.
• Flammability Rating: The 3248030 achieves UL94 V-0 (superior flame resistance) versus UL94 V-2 for the original part, providing enhanced safety performance.
• Stripping Length: The 3248030 requires 9 mm stripping length versus 8 mm for the 1413010. Assembly procedures must be adjusted accordingly.

Selection of the 3248030 is appropriate for applications where the wire gauge range 12-24 AWG and 300 V UL rating satisfy design requirements. Applications with stricter voltage or wire gauge specifications require alternative component evaluation.

Frequently Asked Questions (FAQ)

Q: Can the 3248030 directly replace the 1413010 in all applications?

A: The 3248030 is mechanically and electrically compatible for most applications. However, direct replacement is conditional on two factors: (1) the application does not require 28 AWG wire support, and (2) the circuit voltage does not exceed 300 V UL rating. Verify these parameters against your design specifications before substitution.

Q: What is the significance of the wire gauge range difference (12-28 AWG vs. 12-24 AWG)?

A: The 1413010 accommodates smaller diameter conductors down to 28 AWG, while the 3248030 minimum is 12 AWG. If your design uses 25, 26, 27, or 28 AWG conductors, the 3248030 cannot be used without design modification or alternative component selection.

Q: Why does the 3248030 have a lower UL voltage rating (300 V vs. 600 V)?

A: The 3248030 belongs to the CLIPLINE UT series with different insulation and design specifications optimized for 300 V UL applications. Applications requiring 600 V UL compliance must retain the original 1413010 or identify alternative components rated for that voltage level.

Q: Are there packaging or inventory considerations?

A: The 1413010 is Last Time Buy with 964 units in stock. The 3248030 is an active product with 3,079 units available, ensuring long-term supply continuity. For new designs or long-term production, the 3248030 is the recommended choice.

Q: Does the stripping length difference affect installation?

A: Yes. The 3248030 requires 9 mm wire stripping versus 8 mm for the 1413010. Assembly procedures, tooling, and operator training must be updated to reflect this 1 mm difference to ensure proper termination and electrical contact.

Q: Are both parts RoHS compliant?

A: Yes. The 1413010 is RoHS Compliant, and the 3248030 is ROHS3 Compliant. Both meet current environmental regulations. The 3248030 represents the current compliance standard.
