Equivalent & Substitute Parts for 12CL5-M

Part Overview

The Switchcraft Inc. 12CL5-M is a 5-position circular connector plug with male pins designed for solder termination. This DIN 240-degree connector features a zinc die-cast shell with nickel finish and tin-plated mating contacts, rated for 3A at 34VDC. The connector includes integrated backshell, cable clamp, and strain relief features for robust field installation.

The 12CL5-M is classified as obsolete. Locating direct replacements is necessary for ongoing maintenance, repair, and system support where this connector type is specified in existing installations or legacy equipment designs.

Substiute Parts

12CL5-M

Switchcraft Inc.In Stock: 80412CL5-M Datasheet

Current PartRFQ

12CL5MX

Switchcraft Inc.In Stock: 189812CL5MX Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 12CL5-M is determined by strict equivalence across the following critical parameters:

• Connector type (Plug, Male Pins)
• Position count (5 positions)
• Shell size and insert specification (DIN 240 Degree)
• Termination method (Solder)
• Fastening mechanism (Push-Twist)
• Electrical ratings (3A, 34VDC)
• Physical construction (Zinc die-cast shell, nickel finish, tin-plated contacts)
• Integrated features (Backshell, Cable Clamp, Strain Relief)

The 12CL5MX meets all substitution criteria as a direct equivalent manufactured by Switchcraft Inc. under the same product family with identical electrical and mechanical specifications.

Parameter Comparison

Engineering Selection Recommendations

The 12CL5MX is a direct functional equivalent to the obsolete 12CL5-M. Both connectors share identical electrical ratings, mechanical construction, and interface specifications. The primary distinction is product status: the 12CL5-M is obsolete while the 12CL5MX is active in production.

For new designs or ongoing system support, the 12CL5MX is the appropriate selection. The 12CL5MX provides improved regulatory compliance, meeting ROHS3 requirements compared to the non-compliant 12CL5-M. Both parts maintain equivalent REACH and ECCN classifications.

Inventory availability favors the 12CL5MX, with 1,864 pieces in stock versus 713 pieces for the obsolete 12CL5-M.

Frequently Asked Questions (FAQ)

Q: Can the 12CL5MX directly replace the 12CL5-M in existing installations?

A: Yes. The 12CL5MX is mechanically and electrically identical to the 12CL5-M. Both connectors feature the same 5-position DIN 240-degree configuration, solder termination, push-twist fastening, 3A/34VDC ratings, and integrated backshell with cable clamp and strain relief.

Q: What is the difference between 12CL5-M and 12CL5MX?

A: The connectors are functionally equivalent. The 12CL5MX is the active production variant with ROHS3 compliance, while the 12CL5-M is obsolete and RoHS non-compliant. Both are manufactured by Switchcraft Inc. under the same product family.

Q: Are there packaging differences between these parts?

A: The 12CL5-M packaging specification is not provided. The 12CL5MX is supplied in bulk packaging. Confirm packaging requirements for your application before procurement.

Q: What are the critical parameters for substitution?

A: Substitution requires equivalence in connector type (plug, male pins), position count (5), shell size (DIN 240 Degree), termination method (solder), fastening type (push-twist), electrical ratings (3A/34VDC), and integrated features (backshell, cable clamp, strain relief).

Q: Is the 12CL5MX suitable for new designs?

A: Yes. The 12CL5MX is active in production and meets current regulatory requirements including ROHS3 compliance, making it appropriate for new system designs requiring this connector type.
