TE Connectivity AMP Connectors 1-1634007-0 MMCX Plug Coaxial Connector Equivalent & Substitute Parts

Part Overview

The TE Connectivity AMP Connectors 1-1634007-0 is an MMCX Connector Plug with male pin configuration, rated for 50 Ohms impedance, and designed for through-hole solder termination on printed circuit boards. This component operates across a frequency range up to 6 GHz and is classified as obsolete. Due to its obsolete product status, equivalent and substitute parts from active manufacturers are necessary to maintain design continuity and ensure ongoing component availability for production and repair applications.

Substiute Parts

1-1634007-0

TE Connectivity AMP ConnectorsIn Stock: 10741-1634007-0 Datasheet

Current PartRFQ

1408496-1

TE Connectivity AMP ConnectorsIn Stock: 8411408496-1 Datasheet

DirectRFQ

0734152121

MolexIn Stock: 360020734152121 Datasheet

Parametric EquivalentRFQ

262114

Amphenol RFIn Stock: 981262114 Datasheet

Parametric EquivalentRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitute parts for the TE Connectivity 1-1634007-0 are qualified based on strict electrical and mechanical parameter alignment. All substitute parts must satisfy the following criteria:

Critical Matching Parameters:

• Connector Style: MMCX
• Connector Type: Plug, Male Pin
• Impedance: 50 Ohms
• Contact Termination: Solder
• Shield Termination: Solder
• Mounting Type: Through Hole
• Fastening Type: Snap-On
• Frequency - Max: 6 GHz
• Number of Ports: 1
• Center Contact Material: Brass
• Body Material: Brass
• Body Finish: Gold
• Center Contact Plating: Gold
• Dielectric Material: Polytetrafluoroethylene (PTFE)
• Voltage Rating: 170 V
• Mating Cycles: 500
• Moisture Sensitivity Level (MSL): 1 (Unlimited)

Substitute parts are grouped into two categories: Direct Manufacturer Equivalents and Parametric Equivalents. Direct equivalents are sourced from the same manufacturer (TE Connectivity AMP Connectors) with identical electrical and mechanical specifications. Parametric equivalents are sourced from alternative manufacturers (Molex and Amphenol RF) and provide functional equivalence across all critical parameters while maintaining compatibility with the original design requirements.

Parameter Comparison

Engineering Selection Recommendations

Direct Manufacturer Equivalent:

The TE Connectivity AMP Connectors 1408496-1 is a direct equivalent from the original manufacturer. This part maintains identical electrical and mechanical specifications to the 1-1634007-0 while offering improved compliance status. The 1408496-1 is RoHS Compliant and REACH Affected, providing regulatory advantages over the original obsolete part. Both parts are classified as obsolete; however, the 1408496-1 provides a manufacturer-validated alternative within the same product family.

Parametric Equivalents:

The Molex 0734152121 and Amphenol RF 262114 are parametric equivalents that satisfy all critical electrical and mechanical requirements. Both parts are classified as Active products, ensuring long-term availability and supply chain stability. The Molex 0734152121 offers an extended operating temperature range of -55°C to 165°C compared to the original specification of -55°C to 155°C. Both parametric equivalents are ROHS3 Compliant and REACH Affected, meeting current regulatory requirements.

Selection between the direct manufacturer equivalent and parametric equivalents depends on supply chain requirements, regulatory compliance mandates, and long-term availability needs. Active product status of the parametric equivalents provides superior availability assurance compared to obsolete parts.

Frequently Asked Questions (FAQ)

Q: Can the Molex 0734152121 be used as a direct replacement for the TE Connectivity 1-1634007-0?

A: Yes. The Molex 0734152121 satisfies all critical electrical and mechanical parameters required for functional equivalence. Both parts feature MMCX Plug, Male Pin configuration, 50 Ohms impedance, solder termination, through-hole mounting, snap-on fastening, 6 GHz maximum frequency, and identical material specifications. The Molex part is classified as Active, providing superior long-term availability.

Q: What is the difference between the TE Connectivity 1408496-1 and the Molex 0734152121?

A: Both parts are functionally equivalent across all critical electrical and mechanical parameters. The primary differences are manufacturer origin and product status. The TE Connectivity 1408496-1 is from the original manufacturer but classified as obsolete. The Molex 0734152121 is from an alternative manufacturer and classified as Active. The Molex part also offers an extended operating temperature range of -55°C to 165°C versus -55°C to 155°C for the TE Connectivity part.

Q: Are all substitute parts compatible with the original PCB design?

A: Yes. All substitute parts feature identical through-hole mounting configuration, snap-on fastening type, and mechanical dimensions consistent with MMCX Plug, Male Pin specifications. PCB footprint compatibility is maintained across all listed substitutes.

Q: What is the significance of the Active product status for the Molex and Amphenol RF parts?

A: Active product status indicates that the manufacturer continues to produce and support the component. This ensures ongoing availability, consistent quality, and manufacturer technical support. Obsolete parts, such as the original TE Connectivity 1-1634007-0 and the 1408496-1, have limited remaining inventory and no guarantee of future availability.

Q: Do the substitute parts meet current regulatory requirements?

A: The Molex 0734152121 and Amphenol RF 262114 are both ROHS3 Compliant and REACH Affected, meeting current regulatory standards. The original TE Connectivity 1-1634007-0 is marked as Not applicable for RoHS Status and Vendor Undefined for REACH Status. The TE Connectivity 1408496-1 is RoHS Compliant and REACH Affected, providing improved regulatory alignment.

Q: Is there a difference in packaging between the substitute parts?

A: The original TE Connectivity 1-1634007-0 has no specified packaging designation. The TE Connectivity 1408496-1 also has no specified packaging designation. The Molex 0734152121 and Amphenol RF 262114 are both supplied in Bag packaging. Packaging differences do not affect electrical or mechanical compatibility.

Q: What are the mating cycle ratings for all parts?

A: All listed parts, including the original 1-1634007-0 and all substitutes, are rated for 500 mating cycles. This specification is consistent across all equivalent and substitute parts.

Q: Can the Amphenol RF 262114 be used if operating temperature range is critical?

A: The Amphenol RF 262114 does not specify an operating temperature range in the provided data. If operating temperature range is a critical design parameter, the Molex 0734152121 with its specified range of -55°C to 165°C or the TE Connectivity parts with -55°C to 155°C are preferred selections.
