LINE FILTER 10DVCG5 Equivalent & Substitute Parts

Part Overview

The Delta Electronics 10DVCG5 is a single-phase EMC/EMI line filter rated for 10A at 115V and 250VAC, operating at 50/60Hz. This chassis-mount filter features a two-stage configuration with quick-connect termination, designed for general-purpose applications requiring electromagnetic compatibility filtering. The product maintains active status with full RoHS3 compliance and REACH unaffected designation. Substitute parts are identified when equivalent electrical performance, mechanical compatibility, and regulatory approvals align with the original specification.

Substiute Parts

10DVCG5

Delta ElectronicsIn Stock: 100010DVCG5 Datasheet

Current PartRFQ

FN2080-10-06

Schaffner EMC Inc.In Stock: 1375FN2080-10-06 Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 10DVCG5 is determined by the following critical parameters:

• Electrical Compatibility: Single-phase filter type, two-stage configuration, 10A current rating, and dual voltage operation (110V–250V AC range)
• Frequency Range: Operating frequency must encompass or exceed 50/60Hz minimum requirement
• Mechanical Interface: Chassis-mount form factor with quick-connect termination
• Regulatory Compliance: Active product status with RoHS3 compliance and REACH unaffected designation
• Approval Certifications: Presence of CSA, UR, or equivalent recognized agency approvals

The substitute part FN2080-10-06 meets these criteria through equivalent electrical ratings, compatible mounting and termination methods, and aligned regulatory certifications.

Parameter Comparison

Engineering Selection Recommendations

The FN2080-10-06 qualifies as a direct substitute for the 10DVCG5 based on matched electrical specifications, identical current and voltage ratings within the 110–250V AC range, and equivalent mechanical interfaces. Both components maintain active product status with full RoHS3 compliance and REACH unaffected certification. Regulatory approvals include CSA and UR recognition for both units, with the Schaffner component additionally certified by ENEC. The extended frequency range of the FN2080-10-06 (DC ~ 400Hz) provides operational coverage beyond the 50/60Hz requirement of the Delta unit, supporting broader application flexibility without performance compromise.

Frequently Asked Questions (FAQ)

Q: Can the FN2080-10-06 replace the 10DVCG5 in existing designs?

A: Yes. Both components share identical current ratings (10A), compatible voltage ranges (110–250V AC), matching two-stage single-phase configurations, and equivalent chassis-mount quick-connect interfaces. Active product status and RoHS3 compliance are maintained across both units.

Q: What is the voltage compatibility difference between 115V and 110V ratings?

A: The 10DVCG5 specifies 115V operation while the FN2080-10-06 specifies 110V. Both units are rated for 250V maximum. The 5V difference falls within standard industrial tolerance for AC line voltage variations and does not affect substitution eligibility.

Q: How do the frequency ranges differ?

A: The 10DVCG5 operates at 50/60Hz. The FN2080-10-06 operates across DC ~ 400Hz, providing extended frequency coverage. This broader range supports the original 50/60Hz requirement and additional applications without limitation.

Q: Are the inductance values equivalent?

A: The 10DVCG5 specifies L1 - 1.2mH and L2 - 40mH. The FN2080-10-06 specifies 4.5mH total inductance. Both configurations deliver two-stage filtering appropriate for 10A single-phase EMC/EMI applications.

Q: What packaging differences exist?

A: The 10DVCG5 is supplied in box packaging. The FN2080-10-06 is supplied in tray packaging. Packaging format does not affect electrical or mechanical compatibility for component selection.

Q: Are regulatory certifications equivalent?

A: Both units hold CSA and UR approvals. The 10DVCG5 additionally carries VDE certification. The FN2080-10-06 carries ENEC certification. All certifications are recognized for general-purpose industrial applications.
