TE Connectivity 104656-5 Equivalent & Substitute Parts

Part Overview

The TE Connectivity 104656-5 is a surface mount rectangular connector header with 50 positions arranged in 2 rows at 0.050" (1.27mm) pitch. This connector is part of the AMPMODU 50/50 Grid series and features shrouded 4-wall construction with push-pull fastening. The part is currently active in production with 908 units in stock.

Substitute parts are identified when equivalent electrical and mechanical parameters are maintained across the connector interface, allowing direct functional replacement in board-to-board applications. Substitution becomes necessary due to inventory availability, compliance requirements, or design optimization needs.

Key Parameters

Parameter	Value
Connector Type	Header
Contact Type	Male Pin
Number of Positions	50
Number of Rows	2
Pitch - Mating	0.050" (1.27mm)
Row Spacing - Mating	0.050" (1.27mm)
Mounting Type	Surface Mount
Shrouding	Shrouded - 4 Wall
Fastening Type	Push-Pull
Termination	Solder
Contact Material	Phosphor Bronze
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature Range	-65°C ~ 105°C
Current Rating	0.5A per Contact
Material Flammability Rating	UL94 V-0

Substitute Part Grouping Explanation

Substitute parts are classified into two categories based on electrical and mechanical compatibility with the 104656-5:

Direct Equivalent (Identical Parameters): The part 5-104656-5 maintains all critical electrical and mechanical parameters of the main part, including pitch (0.050"), position count (50), row configuration (2 rows), mounting type (surface mount), shrouding (4-wall), fastening (push-pull), and operating temperature range (-65°C ~ 105°C). The primary distinction is RoHS compliance status and contact finish post material (Tin versus Tin-Lead).

Similar Equivalents (Compatible Parameters with Variations): Parts from Samtec Inc. (TFM-125 series) and Harwin Inc. (G125-MS15005L3P) maintain core mechanical compatibility through identical pitch (0.050" or 0.049"), position count (50), row configuration (2 rows), mounting type (surface mount), shrouding (4-wall), and termination (solder). These parts differ in contact shape (square versus circular), current rating capacity, operating temperature range, and fastening mechanism, which may affect application suitability.

Key Parameters for Substitution Determination:

Pitch - Mating: 0.050" (1.27mm) or 0.049" (1.25mm)
Number of Positions: 50
Number of Rows: 2
Mounting Type: Surface Mount
Shrouding: Shrouded - 4 Wall
Termination: Solder
Contact Material: Phosphor Bronze
Material Flammability Rating: UL94 V-0

Parameter Comparison

Parameter	104656-5 (Main)	5-104656-5	TFM-125-12-L-D	TFM-125-12-S-D-LC	TFM-125-12-SM-D-LC	G125-MS15005L3P
Manufacturer	TE Connectivity	TE Connectivity	Samtec Inc.	Samtec Inc.	Samtec Inc.	Harwin Inc.
Series	AMPMODU 50/50 Grid	AMPMODU 50/50 Grid	Tiger Eye™ TFM	Tiger Eye™ TFM	Tiger Eye™ TFM	Gecko
Connector Type	Header	Header	Header	Header	Header	Header
Contact Type	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin	Male Pin
Number of Positions	50	50	50	50	50	50
Number of Rows	2	2	2	2	2	2
Pitch - Mating	0.050" (1.27mm)	0.050" (1.27mm)	0.050" (1.27mm)	0.050" (1.27mm)	0.050" (1.27mm)	0.049" (1.25mm)
Row Spacing - Mating	0.050" (1.27mm)	0.050" (1.27mm)	0.050" (1.27mm)	0.050" (1.27mm)	0.050" (1.27mm)	0.049" (1.25mm)
Mounting Type	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount
Shrouding	Shrouded - 4 Wall	Shrouded - 4 Wall	Shrouded - 4 Wall	Shrouded - 4 Wall	Shrouded - 4 Wall	Shrouded - 4 Wall
Fastening Type	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Push-Pull	Latch Lock
Termination	Solder	Solder	Solder	Solder	Solder	Solder
Contact Shape	Circular	Circular	Square	Square	Square	Circular
Contact Material	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze	Phosphor Bronze
Insulation Material	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Liquid Crystal Polymer (LCP)	Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
Operating Temperature Range	-65°C ~ 105°C	-65°C ~ 105°C	-55°C ~ 125°C	-55°C ~ 125°C	-55°C ~ 125°C	-65°C ~ 150°C
Current Rating (Amps)	0.5A per Contact	0.5A per Contact	2.9A per Contact	2.9A per Contact	2.9A per Contact	2A per Contact
Material Flammability Rating	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0	UL94 V-0
RoHS Status	RoHS non-compliant	RoHS Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant	ROHS3 Compliant
Product Status	Active	Active	Active	Active	Active	Active
Inventory (Pcs)	908	1050	943	1082	808	1870

Engineering Selection Recommendations

Direct Equivalent Selection: The part 5-104656-5 is the primary direct equivalent to 104656-5. Both parts maintain identical electrical and mechanical specifications, including pitch, position count, row configuration, operating temperature range, and current rating. The 5-104656-5 offers improved compliance status with RoHS Compliant certification, whereas the main part is RoHS non-compliant. Selection of 5-104656-5 is appropriate for applications requiring RoHS compliance or when inventory of the main part is depleted.

Samtec Tiger Eye™ TFM Series Selection: The TFM-125-12-L-D, TFM-125-12-S-D-LC, and TFM-125-12-SM-D-LC parts from Samtec maintain mechanical compatibility through identical pitch (0.050"), position count (50), row configuration (2 rows), and shrouding (4-wall). These parts feature enhanced current rating capacity (2.9A per Contact versus 0.5A), extended operating temperature range (-55°C ~ 125°C), and ROHS3 compliance. The TFM-125-12-S-D-LC and TFM-125-12-SM-D-LC variants include Board Lock features. Selection of Samtec parts is appropriate for applications requiring higher current capacity or extended temperature performance within the -55°C ~ 125°C range.

Harwin Gecko Series Selection: The G125-MS15005L3P from Harwin Inc. maintains mechanical compatibility through identical position count (50), row configuration (2 rows), and shrouding (4-wall). The pitch specification is 0.049" (1.25mm), which differs marginally from the 0.050" (1.27mm) standard. This part features enhanced current rating (2A per Contact), extended operating temperature range (-65°C ~ 150°C), and ROHS3 compliance. The fastening mechanism is Latch Lock rather than Push-Pull. Selection of the G125-MS15005L3P is appropriate for applications requiring extended temperature performance to 150°C or when Latch Lock fastening is preferred.

Compliance Considerations: All substitute parts carry active product status. The 5-104656-5 is RoHS Compliant, while Samtec and Harwin parts are ROHS3 Compliant. Applications subject to RoHS directives should select compliant alternatives. The main part 104656-5 is RoHS non-compliant and REACH Affected; substitute parts offer improved regulatory alignment.

Frequently Asked Questions (FAQ)

Q: Can 5-104656-5 be used as a direct replacement for 104656-5?

A: Yes. The 5-104656-5 maintains identical electrical and mechanical parameters including pitch (0.050"), position count (50), row configuration (2 rows), operating temperature range (-65°C ~ 105°C), and current rating (0.5A per Contact). The primary difference is RoHS compliance status. Both parts are packaged in tubes and feature identical shrouding, fastening, and termination specifications.

Q: What are the key differences between TE Connectivity 104656-5 and Samtec TFM-125 series parts?

A: Both maintain identical pitch (0.050"), position count (50), row configuration (2 rows), and shrouding (4-wall). Key differences include contact shape (circular for 104656-5 versus square for TFM-125), current rating (0.5A versus 2.9A per Contact), operating temperature range (-65°C ~ 105°C versus -55°C ~ 125°C), and fastening mechanism (Push-Pull for both). Samtec parts offer higher current capacity and extended temperature performance within the -55°C ~ 125°C range.

Q: Is the Harwin G125-MS15005L3P compatible with 104656-5?

A: The G125-MS15005L3P maintains mechanical compatibility through identical position count (50), row configuration (2 rows), and shrouding (4-wall). The pitch specification differs at 0.049" (1.25mm) versus 0.050" (1.27mm). The fastening mechanism is Latch Lock rather than Push-Pull. Compatibility depends on application tolerance to pitch variation and fastening mechanism differences. The G125-MS15005L3P offers extended operating temperature range (-65°C ~ 150°C) and higher current rating (2A per Contact).

Q: What packaging formats are available for these connector headers?

A: The 104656-5 and Samtec TFM series parts are packaged in tubes. The Harwin G125-MS15005L3P is packaged in bags. Packaging selection may affect handling, storage, and automated assembly processes.

Q: Which substitute part offers the highest current rating?

A: The Samtec TFM-125 series parts (TFM-125-12-L-D, TFM-125-12-S-D-LC, TFM-125-12-SM-D-LC) offer the highest current rating at 2.9A per Contact, compared to 0.5A per Contact for the main part 104656-5 and 2A per Contact for the Harwin G125-MS15005L3P.

Q: Are all substitute parts RoHS compliant?

A: The 5-104656-5 is RoHS Compliant. The Samtec TFM-125 series parts and Harwin G125-MS15005L3P are ROHS3 Compliant. The main part 104656-5 is RoHS non-compliant. Applications requiring RoHS compliance should select from the compliant alternatives.

Q: What is the difference between TFM-125-12-S-D-LC and TFM-125-12-SM-D-LC?

A: Both parts maintain identical electrical and mechanical specifications including pitch (0.050"), position count (50), row configuration (2 rows), current rating (2.9A per Contact), and operating temperature range (-55°C ~ 125°C). The TFM-125-12-S-D-LC features Board Guide, while the TFM-125-12-SM-D-LC features Board Lock. Selection depends on application requirements for mechanical guidance or locking mechanisms.

Q: Can these connector headers be used in automotive applications?

A: The main part 104656-5 lists automotive applications in its specification. Samtec and Harwin parts do not specify automotive applications in the provided data. Application suitability in automotive environments should be confirmed through detailed design review and compliance verification.
