Part Overview

The 3M 10240-6212VC is a 40-position Mini D Ribbon (MDR) receptacle connector designed for panel mount, through-hole solder termination applications. This connector features shielded outer shroud contacts with gold-plated contact finish and is part of the 3M 102 series connector family.

The 10240-6212VC is classified as obsolete. Identifying equivalent and substitute parts is necessary to maintain design continuity, ensure supply chain availability, and support ongoing production or maintenance requirements for systems utilizing this connector configuration.

Substiute Parts

10240-6212VC

3MIn Stock: 86510240-6212VC Datasheet

Current PartRFQ

10240-6212PC

3MIn Stock: 103410240-6212PC Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the 10240-6212VC is determined by strict equivalence across the following critical parameters:

• Connector type: Receptacle
• Number of positions: 40
• Number of rows: 2
• Mounting type: Panel Mount, Through Hole
• Termination method: Solder
• Connector style: Outer Shroud Contacts
• Series compatibility: 102, Mini D Ribbon (MDR)
• Features: Shielded configuration
• Contact finish: Gold plating at 30.0µin (0.76µm)
• Flange feature: Housing/Shell (M2.6)

Parts meeting all these parameters are classified as direct substitutes. Variations in product status, packaging format, or compliance certifications do not affect functional or mechanical interchangeability.

Parameter Comparison

Engineering Selection Recommendations

The 3M 10240-6212PC is a direct functional and mechanical substitute for the obsolete 10240-6212VC. Both parts are identical across all electrical and mechanical parameters that determine connector interchangeability.

The primary distinction between these parts is product status and compliance certification. The 10240-6212PC is an active product with RoHS compliance, whereas the 10240-6212VC is obsolete and RoHS non-compliant. For new designs or systems requiring RoHS compliance, the 10240-6212PC is the appropriate selection. For legacy system maintenance where RoHS compliance is not a requirement, either part is functionally equivalent.

Packaging differences (bulk format for the substitute versus unspecified for the main part) do not affect connector performance or mechanical fit.

Frequently Asked Questions (FAQ)

Q: Are the 10240-6212VC and 10240-6212PC mechanically interchangeable?

A: Yes. Both connectors share identical mechanical specifications including 40-position configuration, 2-row layout, panel mount through-hole mounting, M2.6 housing/shell flange, and outer shroud contact style. They are direct mechanical substitutes.

Q: What is the difference between these two part numbers?

A: The primary differences are product status and compliance certification. The 10240-6212VC is obsolete and RoHS non-compliant, while the 10240-6212PC is an active product with RoHS compliance. All electrical and mechanical parameters are identical.

Q: Can I use the 10240-6212PC in place of the 10240-6212VC in existing designs?

A: Yes. The 10240-6212PC is a direct substitute with identical connector specifications. No design modifications are required for substitution.

Q: Does packaging format affect connector compatibility?

A: No. Packaging format (bulk versus other formats) does not affect connector electrical performance, mechanical fit, or interchangeability. Packaging differences relate only to order quantity and handling considerations.

Q: Why should I consider the 10240-6212PC over the 10240-6212VC?

A: The 10240-6212PC is recommended for new applications and systems requiring RoHS compliance. As an active product, it offers better long-term supply chain availability compared to the obsolete 10240-6212VC.
