10090096-P094LLF D-Sub 9 Position Plug Connector Equivalent & Substitute Parts
Part Overview
The 10090096-P094LLF is a 9 position D-Sub plug connector with male pins manufactured by Amphenol ICC (FCI). This connector features a board-side M3 flange, solder termination, and is rated for 5A per contact at 250V. The product is currently obsolete, making identification of equivalent and substitute parts essential for system maintenance, repair, and legacy equipment support.
Substiute Parts
Key Parameters
| Parameter | Value |
|---|---|
| Connector Style | D-Sub |
| Connector Type | Plug, Male Pins |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Shell Size, Connector Layout | 1 (DE, E) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Current Rating | 5A per Contact |
| Voltage Rating | 250V |
| Operating Temperature | -55°C ~ 105°C |
| Moisture Sensitivity Level | 1 (Unlimited) |
Substitute Part Grouping Explanation
Substitution of the 10090096-P094LLF is determined by strict equivalence in the following parameters:
- Connector style (D-Sub)
- Connector type (Plug, Male Pins)
- Number of positions (9)
- Number of rows (2)
- Shell size and layout (1 / DE, E)
- Mounting type (Through Hole)
- Termination method (Solder)
Substitute parts must maintain compatibility with these core electrical and mechanical specifications. Variations in flange feature type (board-side vs. housing/shell), shell material finish, contact finish, dielectric material, and operating temperature range are permitted provided the connector maintains the same form factor and functional interface.
Parameter Comparison
| Parameter | 10090096-P094LLF | D09P24A4GL00LF | 09641227235 | 627-009-220-041 | 627-009-220-043 | 627-009-228-041 | 627-009-228-043 | 627-009-228-047 | 627-009-228-048 | 627-009-320-041 | 627-009-320-042 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Amphenol ICC (FCI) | Amphenol ICC (FCI) | HARTING | Mercury United Electronics | Mercury United Electronics | Mercury United Electronics | Mercury United Electronics | Mercury United Electronics | Mercury United Electronics | Mercury United Electronics | Mercury United Electronics |
| Connector Type | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins |
| Number of Positions | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 |
| Shell Size, Connector Layout | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Termination | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder |
| Current Rating (Amps) | 5A per Contact | 5A per Contact | 7.5A | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified |
| Voltage Rating | 250V | 300V | 100V | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified |
| Operating Temperature | -55°C ~ 105°C | -55°C ~ 125°C | -20°C ~ 125°C | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified |
| Product Status | Obsolete | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| RoHS Status | Not specified | RoHS Compliant | ROHS3 Compliant | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified | Not specified |
Engineering Selection Recommendations
The 10090096-P094LLF is obsolete and no longer manufactured. Selection of a substitute part should prioritize active product status and compliance certifications.
Primary Substitute: D09P24A4GL00LF (Amphenol ICC)
The D09P24A4GL00LF is the recommended primary substitute. It maintains identical connector geometry, pin count, and electrical interface with the original part. This connector is active in production, RoHS compliant, and rated for higher voltage (300V) and extended operating temperature (-55°C ~ 125°C). The flange feature differs (housing/shell M3 vs. board-side M3), requiring verification of mechanical fit in the target application.
Secondary Substitute: 09641227235 (HARTING)
The 09641227235 provides equivalent form factor and functionality with active product status and ROHS3 compliance. This connector features a board-side 4-40 flange and higher current rating (7.5A). The operating temperature range (-20°C ~ 125°C) is narrower at the lower end, and voltage rating (100V) is lower than the original specification. This part is suitable for applications where the lower voltage and temperature specifications are acceptable.
Tertiary Substitutes: Mercury United Electronics 627 Series
The Mercury United Electronics 627 series connectors (627-009-220-041, 627-009-220-043, 627-009-228-041, 627-009-228-043, 627-009-228-047, 627-009-228-048, 627-009-320-041, 627-009-320-042) provide equivalent D-Sub 9 position plug configurations with active product status. Detailed electrical specifications for these parts are not provided in the available data. Verification of voltage rating, current rating, and operating temperature range is required before selection.
Frequently Asked Questions (FAQ)
Q: Can the D09P24A4GL00LF directly replace the 10090096-P094LLF?
A: The D09P24A4GL00LF is mechanically and electrically compatible in terms of connector interface, pin count, and form factor. The primary difference is the flange feature location (housing/shell M3 vs. board-side M3). Physical verification of mounting hole alignment and clearance in the target application is required before installation.
Q: What is the difference between board-side and housing/shell flange features?
A: Board-side flanges mount directly to the PCB with fasteners through the flange. Housing/shell flanges are integrated into the connector shell itself. These mounting approaches require different PCB hole patterns and mechanical layouts. Verify your application's mounting configuration before selecting a substitute.
Q: Why is the voltage rating different between substitute parts?
A: Voltage rating is determined by dielectric material, contact spacing, and shell design. The D09P24A4GL00LF uses polybutylene terephthalate (PBT) dielectric rated for 300V, while the HARTING 09641227235 uses polycyclohexylenedimethylene terephthalate (PCT) dielectric rated for 100V. Select a substitute with voltage rating equal to or greater than your application requirement.
Q: Are the Mercury United Electronics 627 series connectors suitable replacements?
A: The 627 series connectors maintain the same D-Sub 9 position plug configuration and are active products. However, detailed electrical specifications (voltage rating, current rating, operating temperature) are not provided in the available data. Contact the manufacturer or distributor for complete specifications before selection.
Q: What is the significance of RoHS compliance?
A: RoHS compliance indicates the connector meets restrictions on hazardous substances in electrical and electronic equipment. The D09P24A4GL00LF is RoHS compliant, and the HARTING 09641227235 is ROHS3 compliant. If your application requires RoHS certification, select a substitute with active RoHS status.
Q: Can I use a connector with a higher operating temperature range?
A: Yes, provided the connector meets or exceeds all other electrical and mechanical requirements of your application. The D09P24A4GL00LF (-55°C ~ 125°C) and HARTING 09641227235 (-20°C ~ 125°C) both support extended temperature ranges. Verify that the higher temperature capability does not introduce incompatibilities with other system components.
