HARTING 09663557513 D-Sub 25 Position Receptacle Connector Equivalent & Substitute Parts
Part Overview
The HARTING 09663557513 is a 25 position D-Sub receptacle connector with female sockets, designed for through-hole solder termination. This connector features a vertical orientation with mating side female screwlock (4-40) and is constructed with steel shell and gold-plated copper alloy contacts. The part is currently active in production and RoHS3 compliant.
Equivalent and substitute parts are necessary when the primary part becomes unavailable, when alternative packaging formats are required for supply chain optimization, or when design flexibility permits selection from qualified alternatives that meet identical electrical and mechanical specifications.
Substiute Parts
Key Parameters
| Parameter | Value |
|---|---|
| Connector Type | D-Sub Receptacle, Female Sockets |
| Number of Positions | 25 |
| Number of Rows | 2 |
| Shell Size, Connector Layout | 3 (DB, B) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Shell Material, Finish | Steel |
| Contact Finish | Gold |
| Current Rating | 6.5A |
| Material Flammability Rating | UL94 V-0 |
| Operating Temperature | -55°C ~ 125°C |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level | 1 (Unlimited) |
Substitute Part Grouping Explanation
Substitution eligibility for the HARTING 09663557513 is determined by strict equivalence across the following critical parameters:
Primary Equivalence Criteria:
- Connector type: D-Sub receptacle with female sockets
- Position count: 25 positions in 2-row configuration
- Shell size and layout: 3 (DB, B)
- Mounting method: Through hole solder termination
- Flange feature: Mating side female screwlock (4-40)
Secondary Compatibility Parameters:
- Contact finish: Gold plating
- Shell material: Steel construction
- Dielectric material: Glass-filled polymer (PCT or Polyester acceptable)
- Flammability rating: UL94 V-0
- Moisture sensitivity: MSL 1
Acceptable Variations:
- Contact material: Copper alloy or phosphor bronze
- Shell finish: Steel or tin-plated steel
- Current rating: 6A or higher
- Operating temperature range: Must encompass -55°C minimum and 105°C or higher maximum
- RoHS compliance: ROHS3 or RoHS compliant acceptable
Substitute parts that deviate from these criteria in mounting type, flange configuration, position count, or shell size are not equivalent and are excluded from this reference.
Parameter Comparison
| Parameter | HARTING 09663557513 | TE 1-338315-2 | TE 1-5745967-0 | TE 1-5745967-4 | TE 1-5745967-5 | TE 1-5745967-6 | TE 1-745967-0 | TE 1-745967-4 | NorComp 172-025-212R011 | NorComp 172-025-212R021 | NorComp 172-E25-213R001 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | HARTING | TE Connectivity | TE Connectivity | TE Connectivity | TE Connectivity | TE Connectivity | TE Connectivity | TE Connectivity | NorComp Inc. | NorComp Inc. | NorComp Inc. |
| Connector Type | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets |
| Number of Positions | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Number of Rows | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Shell Size, Connector Layout | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) | 3 (DB, B) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Panel Mount, Through Hole | Panel Mount, Through Hole | Panel Mount, Through Hole |
| Termination | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder | Solder |
| Shell Material, Finish | Steel | Steel, Tin Plated | Steel, Tin Plated | Steel, Tin Plated | Steel, Tin Plated | Steel, Tin Plated | Steel, Tin Plated | Steel, Tin Plated | Steel, Tin Plated | Steel, Tin Plated | Steel, Nickel Plated |
| Contact Finish | Gold | Gold | Gold | Gold | Gold | Gold | Gold | Gold | Gold | Gold | Gold |
| Current Rating (Amps) | 6.5A | 6A | 6A | 6A | 6A | 6A | 6A | 6A | 5A | 5A | 5A |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 105°C | -50°C ~ 100°C | -50°C ~ 100°C | -50°C ~ 100°C |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Moisture Sensitivity Level | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | 1 (Unlimited) | Not Applicable | Not Applicable | Not Applicable |
| Flange Feature | Mating Side, Female Screwlock (4-40) | Housing/Shell (4-40) | Housing/Shell (4-40) | Mating Side, Female Screwlock (4-40) | Mating Side, Female Screwlock (4-40) | Mating Side, Female Screwlock (4-40) | Housing/Shell (4-40) | Mating Side, Female Screwlock (4-40) | Board Side (4-40) | Board Side (4-40) | Housing/Shell (Unthreaded) |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Obsolete | Obsolete | Active |
Engineering Selection Recommendations
Primary Equivalent (Mating Side Female Screwlock Configuration):
TE Connectivity 1-5745967-4, 1-5745967-5, and 1-5745967-6 are direct functional equivalents to the HARTING 09663557513. All three parts share identical connector geometry, position count, shell size, mounting method, and flange configuration (mating side female screwlock 4-40). These parts are active in production, RoHS3 compliant or RoHS compliant, and maintain the required UL94 V-0 flammability rating. The operating temperature range of -55°C to 105°C encompasses the critical minimum of -55°C specified for the HARTING part. Current rating of 6A is acceptable for applications rated at 6.5A or lower.
Secondary Equivalent (Housing/Shell Configuration):
TE Connectivity 1-338315-2, 1-5745967-0, and 1-745967-0 are functionally equivalent with the exception of flange feature configuration. These parts feature housing/shell (4-40) mounting rather than mating side female screwlock. Selection of these alternatives is appropriate only when the application design permits board-side or housing-side mounting and does not require mating-side screwlock engagement.
Compliance-Restricted Alternatives:
TE Connectivity 1-745967-0 and 1-745967-4 are RoHS non-compliant and should be selected only in applications where RoHS compliance is not mandated or where legacy system compatibility requires non-compliant components.
Temperature-Limited Alternatives:
NorComp 172-025-212R011, 172-025-212R021, and 172-E25-213R001 are panel mount through-hole connectors with reduced operating temperature range (-50°C to 100°C) and lower current rating (5A). These parts are suitable only for applications where the maximum operating temperature does not exceed 100°C and current requirements do not exceed 5A. NorComp parts 172-025-212R011 and 172-025-212R021 are obsolete and should be avoided for new designs.
Frequently Asked Questions (FAQ)
Q: Can TE Connectivity 1-338315-2 be used as a direct replacement for HARTING 09663557513?
A: TE Connectivity 1-338315-2 is functionally equivalent in all critical parameters except flange feature. The HARTING part features mating side female screwlock (4-40), while the TE part features housing/shell (4-40) mounting. Substitution is valid only if the application design accommodates housing/shell mounting rather than mating-side screwlock engagement.
Q: What is the difference between TE 1-5745967-4 and TE 1-5745967-6?
A: Both parts are identical in electrical and mechanical specifications. The difference lies in contact finish thickness: 1-5745967-4 specifies 30.0µin (0.76µm) gold plating, while 1-5745967-6 also specifies 30.0µin (0.76µm). Both meet the gold contact finish requirement. Selection between these parts is based on packaging format and inventory availability.
Q: Are NorComp 172-025-212R021 and 172-E25-213R001 suitable replacements?
A: NorComp 172-025-212R021 is obsolete and not recommended for new designs. NorComp 172-E25-213R001 is active but features panel mount configuration and reduced operating temperature range (-50°C to 100°C) and current rating (5A). Substitution is valid only for applications operating within these reduced specifications.
Q: What is the impact of the 6A current rating on TE parts versus the 6.5A rating on the HARTING part?
A: The TE Connectivity substitute parts are rated at 6A, which is 0.5A lower than the HARTING specification of 6.5A. For applications requiring current capacity above 6A, the HARTING part or equivalent 6.5A-rated alternatives must be selected. For applications at or below 6A, TE parts are acceptable.
Q: Does the operating temperature difference affect substitution eligibility?
A: The HARTING part operates from -55°C to 125°C. TE Connectivity alternatives operate from -55°C to 105°C, and NorComp alternatives from -50°C to 100°C. For applications requiring operation above 105°C, only the HARTING part is suitable. For applications within -55°C to 105°C, TE parts are acceptable. For applications within -50°C to 100°C, NorComp parts are acceptable.
Q: What packaging formats are available for TE Connectivity 1-5745967 series?
A: TE Connectivity offers the 1-5745967 series in tube packaging (1-5745967-0, 1-5745967-4, 1-5745967-5, 1-5745967-6). TE Connectivity 1-338315-2 is available in tray packaging. TE Connectivity 1-745967-0 and 1-745967-4 are available in bulk packaging. Selection of packaging format depends on supply chain requirements and inventory management practices.
Q: Are all substitute parts RoHS3 compliant?
A: No. TE Connectivity 1-5745967-0 and 1-5745967-4 are RoHS compliant but not specifically ROHS3 compliant. TE Connectivity 1-745967-0 and 1-745967-4 are RoHS non-compliant. For applications requiring ROHS3 compliance, select HARTING 09663557513, TE 1-338315-2, TE 1-5745967-5, TE 1-5745967-6, or NorComp alternatives.
