Molex 0875520681 D-Sub Connector: Equivalent & Substitute Parts

Part Overview

The Molex 0875520681 is a 68-position right-angle D-Sub receptacle connector from the EBBI 87552 series, designed for board-to-board applications with .050" contact spacing. This connector is classified as obsolete, making identification of functionally equivalent alternatives essential for ongoing system support and new design implementations. The obsolete status necessitates sourcing from active product lines that maintain electrical and mechanical compatibility with the original specification.

Substiute Parts

0875520681

MolexIn Stock: 11730875520681 Datasheet

Current PartRFQ

1734037-7

TE Connectivity AMP ConnectorsIn Stock: 25121734037-7 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution of the Molex 0875520681 is determined by the following critical parameters:

• Number of Positions: 68 positions (fixed requirement)
• Contact Spacing: .050" (fixed requirement)
• Connector Type: Receptacle (fixed requirement)
• Mounting Type: Right Angle (fixed requirement)
• Connector Category: D-Sub, D-Shaped Connectors (fixed requirement)
• Application Type: Board to Board (fixed requirement)

The TE Connectivity AMP Connectors part 1734037-7 satisfies all these parameters. It is an active product from the CHAMP .050 I series, providing direct functional equivalence to the obsolete Molex connector while offering improved compliance status and current manufacturing availability.

Parameter Comparison

Engineering Selection Recommendations

The TE Connectivity 1734037-7 is the designated manufacturer-recommended substitute for the Molex 0875520681. Selection of this alternative is supported by the following factors:

• Active Product Status: The TE Connectivity connector is an active product with current manufacturing support, ensuring long-term availability and supply chain stability.
• Compliance Improvement: The substitute achieves ROHS3 compliance, addressing regulatory requirements that the obsolete Molex connector does not meet.
• Electrical and Mechanical Equivalence: Both connectors maintain identical position count (68), contact spacing (.050"), connector type (receptacle), mounting orientation (right angle), and application classification (board to board).
• MSL Equivalence: Both connectors share MSL 1 (Unlimited) rating, indicating identical moisture sensitivity characteristics.
• Export Classification Alignment: Both connectors carry the same ECCN classification (EAR99), maintaining consistent export control status.

Frequently Asked Questions (FAQ)

Q: Why is the Molex 0875520681 being discontinued? A: The Molex 0875520681 is classified as obsolete. The TE Connectivity 1734037-7 provides functional equivalence while offering active product status and improved regulatory compliance.

Q: Are the Molex 0875520681 and TE Connectivity 1734037-7 electrically compatible? A: Yes. Both connectors are 68-position receptacles with .050" contact spacing, designed for board-to-board applications with right-angle mounting. They share identical MSL ratings and export classifications.

Q: What is the difference in packaging between these connectors? A: The Molex 0875520681 packaging is not specified in the available data. The TE Connectivity 1734037-7 is supplied in Tray packaging.

Q: Does the TE Connectivity substitute require design modifications? A: Both connectors are right-angle, through-hole, board-to-board receptacles with identical position and spacing specifications. Mechanical and electrical compatibility is maintained. Verify mounting hole patterns and PCB layout compatibility with your specific application.

Q: What compliance advantages does the TE Connectivity connector offer? A: The TE Connectivity 1734037-7 achieves ROHS3 compliance, whereas the Molex 0875520681 is RoHS non-compliant. This addresses regulatory requirements for new designs and systems subject to RoHS directives.

Q: Are there inventory considerations for this substitution? A: The Molex 0875520681 has 1,148 pieces in stock (obsolete inventory). The TE Connectivity 1734037-7 has 2,483 pieces in stock as an active product, providing greater supply availability.
