Molex 0532900510 Equivalent & Substitute Parts

Part Overview

The Molex 0532900510 is a rectangular connector header designed for through-hole mounting with 5 positions at 0.079" (2.00mm) pitch. This connector features a shrouded 3-wall design with kinked pin solder termination and detent lock fastening. The part is classified as obsolete, making equivalent and substitute parts necessary for ongoing design support and procurement.

Substiute Parts

0532900510

MolexIn Stock: 8390532900510 Datasheet

Current PartRFQ

0532530570

MolexIn Stock: 892970532530570 Datasheet

DirectRFQ

0532900580

MolexIn Stock: 11560532900580 Datasheet

DirectRFQ

292161-5

TE Connectivity AMP ConnectorsIn Stock: 19326292161-5 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the Molex 0532900510 is determined by the following critical parameters:

• Pitch - Mating: 0.079" (2.00mm)
• Number of Positions: 5
• Number of Rows: 1
• Connector Type: Header
• Contact Type: Male Pin
• Mounting Type: Through Hole
• Termination: Kinked Pin, Solder
• Fastening Type: Detent Lock
• Contact Material: Brass
• Contact Finish: Tin
• Material Flammability Rating: UL94 V-0
• RoHS Status: ROHS3 Compliant

The substitute parts listed below maintain these core electrical and mechanical parameters. Variations in insulation material, contact length specifications, and style (Board to Board versus Board to Cable/Wire) are noted where they occur, as these may affect mechanical fit and mating interface compatibility.

Parameter Comparison

Engineering Selection Recommendations

Molex 0532900580 is the primary direct substitute for the Molex 0532900510. Both parts share identical series designation (53290), insulation material (PBT glass-filled), contact dimensions, and mechanical specifications. The 0532900580 is active in production, ensuring long-term availability and supply chain stability. This part maintains full compatibility with existing PCB designs and mating interfaces.

Molex 0532530570 is an alternative substitute from the Micro-Latch 53253 series. This part maintains all critical electrical and mechanical parameters but uses polyamide nylon insulation instead of PBT glass-filled material. The insulation height is reduced to 0.217" (5.51mm) compared to 0.236" (6.00mm) in the main part. This part is designated for Board to Cable/Wire applications, whereas the main part is Board to Board. The 0532530570 is active in production with high inventory availability.

TE Connectivity 292161-5 is a manufacturer-recommended substitute from the CT series. This part maintains the core 5-position, 2.00mm pitch header configuration with detent lock fastening. Notable differences include circular contact shape (versus square), increased contact length for mating (0.177" versus 0.130"), and polyamide PA66 nylon insulation. The part is rated for 125VAC operation and is designated for Board to Cable/Wire applications. This part is active in production.

All three substitute parts are ROHS3 compliant, UL94 V-0 rated, and carry MSL 1 (Unlimited) moisture sensitivity classification, matching the compliance profile of the main part.
