Phoenix Contact 0441517 Terminal Block Ground Connector - Equivalent & Substitute Parts

Part Overview

The Phoenix Contact 0441517 is a 2-position ground terminal block connector rated for 10-26 AWG wire gauges. This component is classified as Last Time Buy, indicating discontinued production status. The CLIPLINE USLKG series connector features screw termination with polyamide insulation and UL94 V-0 flammability rating. Due to its Last Time Buy status, identifying functionally equivalent substitute parts is essential for ongoing system maintenance and new design implementations.

Substiute Parts

0441517

Phoenix ContactIn Stock: 8670441517 Datasheet

Current PartRFQ

3044128

Phoenix ContactIn Stock: 34653044128 Datasheet

MFR RecommendedRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the Phoenix Contact 0441517 is determined by the following critical parameters:

• Number of Positions: Must equal 2
• Wire Gauge Range (AWG): Must accommodate 10-26 AWG minimum
• Wire Gauge Range (mm²): Must accommodate 0.2-6 mm² minimum
• Terminal Width: Must equal 6.2 mm
• Termination Style: Must be Screw
• Material - Insulation: Must be Polyamide (PA), Nylon
• Flammability Rating: Must be UL94 V-0
• Type: Must be Ground, Earth
• Color: Must be Green, Yellow

The Phoenix Contact 3044128 meets all substitution criteria. While it belongs to the CLIPLINE UT series (versus CLIPLINE USLKG), it maintains identical electrical and mechanical specifications for the critical parameters listed above. The 3044128 is currently in Active product status with higher inventory availability.

Parameter Comparison

Engineering Selection Recommendations

The Phoenix Contact 3044128 is the qualified substitute for the 0441517. Both components maintain identical compliance certifications including ROHS3 compliance and REACH affected status. The 3044128 offers the advantage of Active product status, ensuring continued availability and supply chain stability compared to the Last Time Buy status of the 0441517.

The wire gauge range of the 3044128 extends to 0.14 mm² minimum (versus 0.2 mm² for the 0441517), providing broader compatibility with smaller gauge conductors while maintaining the 6 mm² maximum. The stripping length difference of 1 mm (9 mm versus 8 mm) represents a minor variation within standard installation tolerances for screw-terminated ground blocks.

Both components share identical electrical classification, mechanical dimensions, and material specifications, confirming direct functional equivalence for ground terminal block applications.

Frequently Asked Questions (FAQ)

Q: Can the Phoenix Contact 3044128 directly replace the 0441517 in existing installations?

A: Yes. Both components are 2-position ground terminal blocks with identical wire gauge ratings (10-26 AWG), terminal width (6.2 mm), screw termination, polyamide insulation, and UL94 V-0 flammability rating. The 1 mm difference in stripping length (9 mm versus 8 mm) does not affect functional compatibility.

Q: What is the significance of the series designation change from CLIPLINE USLKG to CLIPLINE UT?

A: The series designation reflects product line evolution within Phoenix Contact's terminal block portfolio. The CLIPLINE UT series represents the current active production line, while CLIPLINE USLKG is discontinued. Both series maintain identical specifications for the critical electrical and mechanical parameters that determine ground terminal block functionality.

Q: Are there compliance differences between the two parts?

A: No. Both the 0441517 and 3044128 carry identical compliance certifications: ROHS3 compliant, REACH affected, UL94 V-0 flammability rating, and EAR99 ECCN classification.

Q: Why does the 3044128 have a wider wire gauge range (0.14-6 mm² versus 0.2-6 mm²)?

A: The extended lower range of the 3044128 provides enhanced compatibility with smaller gauge conductors. This represents an improvement in the substitute part and does not create any compatibility issues with the original 0.2-6 mm² specification range.

Q: What packaging differences exist between these parts?

A: The 0441517 is supplied in Bulk packaging, while the 3044128 is supplied in Box packaging. This represents a logistical difference only and does not affect electrical or mechanical performance.
