Molex 0393550002 Terminal Block Header - Equivalent & Substitute Parts
Part Overview
The Molex 0393550002 is a 2-position terminal block header with male pins, shrouded design, and 4.6mm pitch configured for 90° right-angle through-hole mounting. This component is classified as obsolete, making identification of functionally equivalent alternatives essential for ongoing system support and new design implementations. The part operates at 10A (UL) and 300V, suitable for industrial control and power distribution applications requiring reliable solder termination.
Substiute Parts
Key Parameters
| Parameter | Value |
|---|---|
| Manufacturer Part Number | 0393550002 |
| Manufacturer | Molex |
| Category | Terminal Blocks |
| Number of Positions | 2 |
| Pitch | 0.138" (4.60mm) |
| Header Orientation | 90°, Right Angle |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current Rating (UL) | 10 A |
| Voltage Rating (UL) | 300 V |
| Operating Temperature | 140°C |
| Product Status | Obsolete |
| RoHS Status | ROHS3 Compliant |
Substitute Part Grouping Explanation
Substitution eligibility for the Molex 0393550002 is determined by the following critical parameters:
- Pitch and Position Count: 0.138" (4.60mm) spacing with 2-position configuration
- Connector Type: Header with male pins, shrouded (4-side) design
- Orientation: 90° right-angle through-hole mounting
- Electrical Ratings: Minimum 10A (UL) current capacity and 300V voltage rating
- Termination Method: Solder termination compatibility
- Compliance: ROHS3 compliance and EAR99 classification
The TE Connectivity AMP Connectors part number 284512-2 meets all substitution criteria within the allowed parameter tolerance range.
Parameter Comparison
| Parameter | Molex 0393550002 | TE Connectivity 284512-2 | Compatibility |
|---|---|---|---|
| Number of Positions | 2 | 2 | Match |
| Positions Per Level | 2 | 2 | Match |
| Pitch | 0.138" (4.60mm) | 0.138" (4.60mm) | Match |
| Header Orientation | 90°, Right Angle | 90°, Right Angle | Match |
| Type | Header, Male Pins, Shrouded (4 Side) | Header, Male Pins, Shrouded (4 Side) | Match |
| Termination Style | Solder | Solder | Match |
| Mounting Type | Through Hole | Through Hole | Match |
| Current Rating (UL) | 10 A | 11 A | Compatible (higher rating) |
| Voltage Rating (UL) | 300 V | 300 V | Match |
| Contact Mating Finish | Tin | Tin | Match |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | Match |
| ECCN | EAR99 | EAR99 | Match |
| Product Status | Obsolete | Active | Substitute is active production |
Engineering Selection Recommendations
The TE Connectivity AMP Connectors 284512-2 is the qualified substitute for the obsolete Molex 0393550002. Selection is based on:
- Electrical Equivalence: Both parts maintain 300V voltage rating with compatible current capacity (11A vs. 10A nominal)
- Mechanical Compatibility: Identical pitch (4.60mm), position count (2), orientation (90° right-angle), and shrouded male pin configuration ensure PCB footprint and mating compatibility
- Regulatory Compliance: Both parts are ROHS3 compliant and classified as EAR99, meeting current environmental and export requirements
- Production Status: The substitute is in active production with confirmed inventory availability (19,591 pcs), ensuring long-term supply chain reliability compared to the obsolete original part
- Termination Compatibility: Solder termination method is identical, requiring no assembly process modification
Frequently Asked Questions (FAQ)
Q: Can the TE Connectivity 284512-2 be used as a direct replacement for the Molex 0393550002 on existing PCBs?
A: Yes. Both parts share identical pitch (4.60mm), position count (2), orientation (90° right-angle), and shrouded male pin configuration. PCB footprints and mounting holes are compatible. No layout modifications are required.
Q: Are there electrical rating differences between these parts?
A: The TE Connectivity 284512-2 has a slightly higher current rating (11A vs. 10A at UL). Voltage rating remains 300V for both. The substitute meets or exceeds the original part's electrical specifications.
Q: What is the difference in operating temperature range?
A: The Molex 0393550002 operates to 140°C maximum. The TE Connectivity 284512-2 operates from -40°C to 110°C. For applications requiring sustained operation above 110°C, the original Molex specification must be verified against actual system requirements.
Q: Are both parts RoHS compliant?
A: Yes. Both the Molex 0393550002 and TE Connectivity 284512-2 are ROHS3 compliant and REACH unaffected, meeting current environmental regulations.
Q: What is the packaging difference?
A: The Molex part is supplied in standard packaging (not specified). The TE Connectivity 284512-2 is supplied in bulk packaging. Verify packaging requirements for your procurement and assembly processes.
Q: Can I use the TE Connectivity part in new designs?
A: Yes. The TE Connectivity 284512-2 is in active production status with confirmed inventory. It is suitable for both replacement applications and new design implementations requiring 2-position, 4.6mm pitch terminal block headers with 90° right-angle through-hole mounting.
