VB525SP
STMicroelectronics
IC PWR DRVR BIPOLAR 1:1 PWRSO10
2190 Pcs New Original In Stock
Power Switch/Driver 1:1 Bipolar 9A 10-PowerSO
Request Quote
(Ships tomorrow)
*Quantity
Minimum 1
Minimum 1
5.0 / 5.0
- (257 Ratings)
VB525SP
Product Overview
8143997
DiGi Electronics Part Number
VB525SP-DGManufacturer
STMicroelectronics
VB525SP
Description
IC PWR DRVR BIPOLAR 1:1 PWRSO10Inventory
2190 Pcs New Original In Stock
Power Switch/Driver 1:1 Bipolar 9A 10-PowerSO
Quantity
Minimum 1
Minimum 1
Purchase and inquiry
Warranty & Returns
How to Order
Shipping & Delivery
Quality Assurance
365 - Day Quality Guarantee - Every part fully backed.
90 - Day Refund or Exchange - Defective parts? No hassle.
Limited Stock, Order Now - Get reliable parts without worry.
Global Shipping & Secure Packaging
Worldwide Delivery in 3-5 Business Days
100% ESD Anti-Static Packaging
Real-Time Tracking for Every Order
Secure & Flexible Payment
Credit Card, VISA, MasterCard, PayPal, Western Union, Telegraphic Transfer(T/T) and more
All payments encrypted for security
VB525SP Technical Specifications
Category
Power Management (PMIC), Power Distribution Switches, Load Drivers
Packaging
-
Series
VIPOWER™
Product Status
Obsolete
Switch Type
General Purpose
Number of Outputs
1
Ratio - Input:Output
1:1
Output Configuration
Low Side
Output Type
Bipolar
Interface
On/Off
Voltage - Load
4.5V ~ 5.5V
Voltage - Supply (Vcc/Vdd)
-
Current - Output (Max)
9A
Rds On (Typ)
-
Input Type
Non-Inverting
Features
Status Flag
Fault Protection
Current Limiting (Fixed), Over Temperature
Operating Temperature
-40°C ~ 150°C (TJ)
Mounting Type
Surface Mount
Supplier Device Package
10-PowerSO
Package / Case
PowerSO-10 Exposed Bottom Pad
Base Product Number
VB525
