DF11C-28DP-2V(57)
Hirose Electric Co Ltd
CONN HEADER SMD 28POS 2MM
811 Pcs New Original In Stock
Connector Header Surface Mount 28 position 0.079" (2.00mm)
Request Quote
(Ships tomorrow)
*Quantity
Minimum 1
Minimum 1
5.0 / 5.0
- (223 Ratings)
DF11C-28DP-2V(57)
Product Overview
6892640
DiGi Electronics Part Number
DF11C-28DP-2V(57)-DGManufacturer
Hirose Electric Co Ltd
DF11C-28DP-2V(57)
Description
CONN HEADER SMD 28POS 2MMInventory
811 Pcs New Original In Stock
Connector Header Surface Mount 28 position 0.079" (2.00mm)
Quantity
Minimum 1
Minimum 1
Purchase and inquiry
Warranty & Returns
How to Order
Shipping & Delivery
Quality Assurance
365 - Day Quality Guarantee - Every part fully backed.
90 - Day Refund or Exchange - Defective parts? No hassle.
Limited Stock, Order Now - Get reliable parts without worry.
Global Shipping & Secure Packaging
Worldwide Delivery in 3-5 Business Days
100% ESD Anti-Static Packaging
Real-Time Tracking for Every Order
Secure & Flexible Payment
Credit Card, VISA, MasterCard, PayPal, Western Union, Telegraphic Transfer(T/T) and more
All payments encrypted for security
DF11C-28DP-2V(57) Technical Specifications
Category
Rectangular Connectors, Headers, Male Pins
Packaging
Tape & Reel (TR)
Series
DF11
Product Status
Active
Connector Type
Header
Contact Type
Male Pin
Pitch - Mating
0.079" (2.00mm)
Number of Positions
28
Number of Rows
2
Row Spacing - Mating
0.079" (2.00mm)
Number of Positions Loaded
All
Style
Board to Board or Cable
Shrouding
Shrouded - 4 Wall
Mounting Type
Surface Mount
Termination
Solder
Fastening Type
Detent Lock
Contact Length - Mating
-
Contact Length - Post
-
Overall Contact Length
-
Insulation Height
0.283" (7.19mm)
Contact Shape
Circular
Contact Finish - Mating
Gold
Contact Finish Thickness - Mating
8.00µin (0.203µm)
Contact Finish - Post
-
Contact Material
Brass
Insulation Material
Polyamide (PA), Nylon
Features
Pick and Place, Solder Retention
Operating Temperature
-30°C ~ 85°C
Ingress Protection
-
Material Flammability Rating
UL94 V-0
Insulation Color
Beige
Current Rating (Amps)
2A
Voltage Rating
250V
Mated Stacking Heights
8.2mm, 8.45mm, 9.55mm
Contact Finish Thickness - Post
-
Applications
-
Base Product Number
DF11C
Datasheet & Documents
HTML Datasheet
DF11C-28DP-2V(57)-DG
Environmental & Export Classification
RoHS Status
RoHS Compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
ECCN
EAR99
HTSUS
8536.69.4040
Additional Information
Other Names
543-0694-0-57
Standard Package
500
