MEC6-130-02-S-DV-A-TR Equivalent & Substitute Parts

Part Overview

The MEC6-130-02-S-DV-A-TR is a 60-position female card edge connector manufactured by Samtec Inc., designed for dual edge applications with 0.025" (0.64mm) pitch spacing. This connector features surface mount solder termination, phosphor bronze contacts with gold finish, and operates across -55°C to 125°C. The part is Active status and ROHS3 compliant, making it suitable for applications requiring reliable edge card interconnection in industrial and commercial environments. Alternative packaging configurations are available to accommodate different procurement and assembly requirements.

Substiute Parts

MEC6-130-02-S-DV-A-TR

Samtec Inc.In Stock: 1139MEC6-130-02-S-DV-A-TR Datasheet

Current PartRFQ

MEC6-130-02-S-DV-A

Samtec Inc.In Stock: 1192MEC6-130-02-S-DV-A Datasheet

SimilarRFQ

Key Parameters

Substitute Part Grouping Explanation

Substitution eligibility for the MEC6-130-02-S-DV-A-TR is determined by strict equivalence across the following critical parameters:

• Manufacturer: Samtec Inc.
• Series: MEC6 - DV
• Number of Positions: 60
• Gender: Female
• Pitch: 0.025" (0.64mm)
• Card Type: Non Specified - Dual Edge
• Number of Rows: 2
• Card Thickness: 0.062" (1.57mm)
• Mounting Type: Surface Mount
• Termination: Solder
• Contact Material: Phosphor Bronze
• Contact Finish: Gold
• Operating Temperature Range: -55°C ~ 125°C
• Insulation Material: Liquid Crystal Polymer (LCP)

The primary difference between the main part and its substitute lies in packaging configuration. The MEC6-130-02-S-DV-A-TR is supplied in Tape & Reel (TR) format, while the substitute MEC6-130-02-S-DV-A is supplied in Tray packaging. Both parts maintain identical electrical and mechanical specifications, ensuring functional interchangeability in circuit applications.

Parameter Comparison

Engineering Selection Recommendations

Both the MEC6-130-02-S-DV-A-TR and MEC6-130-02-S-DV-A maintain Active product status and full ROHS3 compliance. Selection between these parts should be based on procurement and assembly workflow requirements:

The MEC6-130-02-S-DV-A-TR in Tape & Reel packaging is optimized for automated pick-and-place assembly processes, providing continuous component feed and reduced handling time in high-volume manufacturing environments.

The MEC6-130-02-S-DV-A in Tray packaging is suitable for manual assembly operations, kit-based procurement, or applications where automated feeder compatibility is not required.

Both configurations deliver identical electrical performance, mechanical fit, and environmental compliance across the specified operating temperature range of -55°C to 125°C.

Frequently Asked Questions (FAQ)

Q: Are MEC6-130-02-S-DV-A-TR and MEC6-130-02-S-DV-A electrically identical?

A: Yes. Both parts are functionally equivalent with identical electrical specifications, contact materials, finishes, and operating temperature ranges. The only difference is packaging format.

Q: What is the difference between Tape & Reel and Tray packaging?

A: Tape & Reel (TR) packaging supplies components on continuous carrier tape suitable for automated assembly equipment. Tray packaging supplies components in static-dissipative trays for manual handling and assembly. Both formats contain the same connector specifications.

Q: Can I substitute MEC6-130-02-S-DV-A for MEC6-130-02-S-DV-A-TR in my design?

A: Yes, from an electrical and mechanical standpoint. However, packaging format affects procurement logistics and assembly process compatibility. Verify your assembly equipment and supply chain requirements before substitution.

Q: Are both parts ROHS3 compliant?

A: Yes. Both MEC6-130-02-S-DV-A-TR and MEC6-130-02-S-DV-A are ROHS3 compliant with MSL rating of 1 (Unlimited).

Q: What is the pitch specification for these connectors?

A: Both parts feature 0.025" (0.64mm) pitch spacing, which determines compatibility with corresponding card edge designs and mating connectors.

Q: What is the contact finish specification?

A: Both parts use gold-plated phosphor bronze contacts with 30.0µin (0.76µm) finish thickness, providing corrosion resistance and reliable electrical contact.
