Dialight 5530210 LED Circuit Board Indicator - Equivalent & Substitute Parts

Part Overview

The Dialight 5530210 is a 3mm bi-level LED circuit board indicator featuring dual outputs: one high red LED and one blank position. This through-hole, right-angle mounted component operates at 1.7V with 2mA current consumption and delivers 10mcd brightness at a 60° viewing angle. The component is classified as obsolete, making identification of active equivalent parts essential for ongoing production and maintenance applications.

Substiute Parts

5530210

DialightIn Stock: 9855530210 Datasheet

Current PartRFQ

5530210F

DialightIn Stock: 8355530210F Datasheet

DirectRFQ

Key Parameters

Substitute Part Grouping Explanation

The Dialight 5530210F serves as a direct substitute for the 5530210 based on matching electrical and mechanical parameters. Substitution is valid when the following criteria are met:

• Identical configuration: 2 High bi-level arrangement
• Matching color output: Red (x 1), Blank (x 1)
• Identical wavelength: 650nm peak
• Identical electrical specifications: 1.7V voltage rating, 2mA current, 10mcd brightness
• Identical viewing angle: 60°
• Identical lens properties: Diffused, Tinted
• Identical mounting: Through Hole, Right Angle

The primary distinction between these parts is product status and lens style specification. The 5530210F is classified as active and includes explicit lens style designation (Round with Domed Top, 3mm T-1), whereas the 5530210 is obsolete with unspecified lens style parameters.

Parameter Comparison

Engineering Selection Recommendations

The 5530210F is the appropriate selection for applications currently using the obsolete 5530210. All critical electrical parameters—voltage rating, current consumption, brightness output, and viewing angle—are identical between the two parts. Both components maintain the same MSL classification and regulatory status under REACH and ECCN guidelines.

The 5530210F carries active product status and ROHS3 compliance certification, providing assurance of ongoing availability and environmental regulatory alignment. The explicit lens style and size specifications (Round with Domed Top, 3mm T-1) in the 5530210F documentation provide additional clarity for design verification and procurement purposes.

Frequently Asked Questions (FAQ)

Q: Can the 5530210F directly replace the 5530210 in existing designs?

A: Yes. The 5530210F maintains identical electrical specifications (1.7V, 2mA, 10mcd), configuration (2 High), color output (Red/Blank), and mounting type (Through Hole, Right Angle). Both components are classified as REACH Unaffected and carry EAR99 ECCN designation.

Q: What is the primary reason for substitution?

A: The 5530210 is classified as obsolete. The 5530210F is the active equivalent from the same manufacturer and series, ensuring continued component availability.

Q: Are there packaging differences between these parts?

A: The 5530210 packaging is listed as unspecified. The 5530210F is supplied in Bulk packaging. Verify packaging requirements for your procurement process.

Q: Do both parts meet current environmental compliance standards?

A: Both parts are REACH Unaffected. The 5530210F carries explicit ROHS3 Compliant certification, while the 5530210 compliance status is not specified in available documentation.

Q: Are the lens specifications identical?

A: Both parts feature Diffused, Tinted lens type with 60° viewing angle. The 5530210F specifies lens style as Round with Domed Top, 3mm T-1. The 5530210 lens style is not specified in available documentation.
